Collingwood Tilt Adjustable 165mm Cut-Out Ground Light - RGBW - Stainless Steel - Low Voltage

A Colour Changing Ground Light You Can Park On

This is Collingwood's Tilt ground light in the 165mm cut out size, specified as an RGBW colour changing fitting on a low voltage supply. It handles two jobs that usually need two separate products. It can throw red, green, blue or a warm 3000K white across a surface, and it will take the weight of a car while doing it. Collingwood rates the housing to a 2000kg static load and clears it for vehicles up to 15mph, so it can be set into a driveway rather than kept safely out of the way in a planted border. The other useful part is the tilt. Most recessed ground lights fire straight up and that is all they will ever do. This one lets you angle the 40 degree beam by as much as 25 degrees, so a fitting sunk flat into paving can still wash a wall, a gate pier or a tree trunk.

316 Stainless Steel Bezel Over an Anodised Aluminium Body

The part you see once the ground is made good is a 316 stainless steel bezel, brushed to a soft grey, with two countersunk fixing screws set into the face. Everything below it is anodised aluminium. 316 is the marine grade of stainless, the one specified for coastal and poolside work, because it stands up to salt and chloride far better than the standard grade does. That brushed grey face is quiet enough to sit against almost any surface: grey porcelain paving, buff sandstone, block paving, resin bound gravel or a timber deck. The bezel measures 180mm across with 168mm of depth below it, and the unit weighs 2kg.

How It Works

The LEDs are integrated, arranged as a cluster of faceted lenses behind a recessed glass front. RGBW means there is a dedicated white emitter working alongside the red, green and blue, so the white output is a genuine 3000K rather than a colour mix pretending to be white. Power draw depends on what you are asking it to do: 4.5W in red, 5W in green or blue, and 5.5W in white. Collingwood quotes an output range of 100 to 300 lumens across the colours, with a CRI of 80 on the white. This is a low voltage, Class III fitting, which means it needs a separate driver to run and one is not supplied with it. Fittings on this range are wired in series, and each one arrives with a metre of cable already attached so there is something to work with at the bottom of the hole. The tilt is set by turning a knob on the unit before you backfill and finish around it, so aim it while you still have access.

Where It Works Best

The drive over rating is what opens up the difficult positions. Set these into the driveway itself, into a turning circle or a parking bay, across a threshold where a path meets a gate, or along the edge of a patio where a border light would just get kicked. Angle the head and they become uplighters for a rendered wall, a specimen tree, a hedge line or a run of columns. On a commercial forecourt or a hotel approach the RGBW output earns its keep, letting a client change the scheme for a season or an event and drop back to warm white the rest of the year. The 316 bezel and IP67 sealing make it a sensible choice around pools and on coastal sites. That same IP67 rating puts it well above the IP44 threshold, so it can also be used in a bathroom, and our guide to bathroom lighting zones explains where each rating is allowed.

About Collingwood Lighting

Collingwood designs and manufactures its LED products in Sywell, Northamptonshire, and has worked in LED technology and nothing else since 2002. The brand states that it was among the first to bring fire rated, fully sealed for life and mains dimmable LED products to the UK electrical wholesale market. It also holds an EcoVadis Gold medal, which places it in the top 5% of companies assessed worldwide for sustainability. For an outdoor fitting that gets buried in concrete, that focus on sealed, long life construction is the point.

Good to Know

• Warranty: 5 years from Collingwood.
• IP67 rated, meaning fully protected against dust and against temporary immersion in water, which is what a recessed ground fitting needs when a driveway floods.
• IK10 impact rated and cleared for drive over use at up to 15mph, with a 2000kg static load rating.
• Cut out required is 165mm. The bezel is 180mm in diameter and the body needs 168mm of depth below the surface, so allow for that plus drainage when you set out.
• Electrical class: Class III, low voltage. A driver is required and is not included, so specify one to suit the number of fittings on the run.
• Wired in series, with 1 metre of cable supplied on each fitting.
• Tilt is adjustable up to 25 degrees and the beam angle is 40 degrees. Set the tilt before the surface is finished around the fitting.
• Care: rinse the bezel with clean water now and then, especially on coastal sites, and keep the glass clear of grit and leaf litter. Avoid abrasive pads on the stainless steel.
• Moonlight Design recommends installation by a registered NICEIC electrician.

Questions People Ask

Can you drive a car over the Collingwood Tilt 165mm ground light?
Yes. The Collingwood Tilt 165mm cut out ground light is rated to a 2000kg static load and is cleared by the manufacturer for vehicles driving over it at speeds up to 15mph, which suits domestic driveways and low speed parking areas.

Does the Collingwood Tilt RGBW ground light come with a driver?
No. This is a low voltage Class III fitting and no driver is supplied with it. A separate LED driver must be specified and installed, sized for the number of fittings wired on the circuit.

How far can the beam be angled on a Tilt ground light?
The head of the Collingwood Tilt ground light adjusts by up to 25 degrees from vertical, and the beam itself spreads at 40 degrees. The adjustment is made by turning a knob on the fitting, so it should be aimed before the surrounding surface is made good.

What does RGBW mean on this ground light?
RGBW means the fitting contains a separate white LED alongside the red, green and blue emitters. On this Collingwood ground light the white channel runs at 3000K with a CRI of 80, so warm white light comes from a dedicated source rather than being mixed from the colour channels.

Is the Collingwood Tilt 165mm ground light suitable for a coastal property?
Yes. The visible bezel is 316 stainless steel, the marine grade used for its resistance to salt and chloride corrosion, and the fitting is sealed to IP67 with an anodised aluminium body below the surface.

180mm diameter x 168mm depth (refer to spec for details)
