Collingwood GL040 SPS LED Ground Light - Antique Brass - Low Voltage

A Ground Light That Disappears Until It's Switched On

Set the GL040 into a path, patio or flower bed and in daylight you'll barely notice it's there. Switch it on and it throws a clean, focused beam upward, picking out a wall, a tree or the edge of a step without any visible fitting to distract from the effect.

Antique Brass with a Single Point Source Lens

This version is finished in antique brass, a solid brass body that will age and darken naturally outdoors rather than staying showroom bright. It uses a single point source lens rather than multiple LEDs, giving a tighter, more defined beam than you get from a diffused ground light.

How It Works

• Low voltage, Class III fitting that needs a separate driver, not a standard mains connection
• Wired in series with other GL040 fittings on the same circuit, so the driver is sized to the whole run rather than one light
• Available with a 12° beam for a tighter spot or a 40° beam for a wider spread
• Comes in 2700K or 3000K depending on which variant you choose, both warm white
• Dimmable when paired with a suitable driver

Where It Works Best

Because it's IP68 rated and carries a walk over rating, the GL040 isn't limited to flower beds. It can be set into a path, patio or driveway where people and vehicles will pass over it, and it's rated to be fully submerged, so it also works set beneath a shallow pond or water feature. Use the 12° version to graze up a wall or tree trunk, or the 40° version to wash a wider area of planting or paving.

About Collingwood Lighting

Collingwood Lighting designs and manufactures its LED products from Sywell in Northamptonshire, and has specialised in LED technology since 2002. Fittings like the GL040, rated IP68 and built to be walked over or submerged, reflect a brand that says it was among the first to bring fully sealed, waterproof LED products to the UK electrical wholesale market. Collingwood has also been awarded a Gold medal by EcoVadis, ranking it in the top 5% of companies assessed globally for sustainability.

Good to Know

• IP68 rated: fully submersible and suited to paths, patios, driveways, pond surrounds and water features
• Walk over rated with IK08 impact resistance
• Class III low voltage fitting, requires a separate driver, wired in series with other fittings on the circuit
• Dimmable with a suitable driver
• 76mm diameter body with a 70mm cut out and 41mm depth, weighs 0.7kg
• 7 year warranty
• Moonlight Design recommends installation by a registered NICEIC electrician

Questions People Ask

Can the GL040 be installed under water?
Yes. It's IP68 rated, which means it can be fully submerged, so it can be set beneath a shallow pond or water feature as well as buried in the ground.

Do I need to buy a driver separately?
Yes. This is a low voltage, Class III light and needs a separate driver. It's wired in series with other fittings on the same circuit rather than each light having its own driver.

Can it be walked or driven over once installed?
Yes. It carries a walk over rating and IK08 impact resistance, so it can be set into paths, patios and driveways.

Will the antique brass finish stay the same colour?
No. Being a natural brass finish, it will weather and darken with exposure over time, which many people like for a more traditional garden look.

What's the difference between the 12° and 40° versions?
The 12° beam gives a tighter, more focused spot, useful for grazing up a wall or tree trunk. The 40° beam spreads light more widely across paving or planting.

76mm diameter x 41mm depth
