Collingwood SL230 LED Twin Pole Spike Light - Black - Low Voltage

Two beams, one spike, one cable run

The Collingwood SL230 puts two separate LED spot heads on a single slim pole, so one hole in the ground and one cable run do the work of two fittings. Each head aims on its own. That means you can wash a tree canopy with one and drop light onto the path beside it with the other. At 845mm to the top of the pole it sits above low planting rather than getting swallowed by it, and the twin head arrangement keeps light where you want it without a second trench across the lawn.

Black anodised aluminium, low voltage

This is the black low voltage SL230, product reference SL230BWBX. The body is anodised aluminium rather than painted, so the colour is part of the metal itself and copes far better with a knock from a mower or a stray boot than a sprayed coating would. It is a deep satin black, not a gloss, which is exactly what you want outdoors. It stops the fitting flaring in daylight and lets the pole disappear into hedging, dark mulch or a slate chipping border once the sun goes down. Collingwood lists the SL230 as suitable for coastal areas, so salt laden air is not a problem. It sits happily alongside other dark garden hardware such as black railings, charcoal fencing and dark grey porcelain paving.

How It Works

The SL230 is a low voltage SELV fitting, so it does not connect to the mains directly. It runs from a separate constant current LED driver, which is not included and needs to be chosen to suit the number of fittings on the run. At 350mA each head draws 4.4W and Collingwood publishes 580 lumens per head at that setting. Step the driver up to 700mA and each head draws 9.2W for a noticeably brighter result. Fittings wire in series, and Collingwood names the DRV150700, the dimmable DRV350700TD and the PSIP70036W among its recommended drivers. Each unit comes as the spiked pole with the twin head assembly fitted and a 3m H05RN-F rubberised flying lead of 6mm outside diameter. Both heads tilt through 90 degrees and rotate through 330 degrees independently, and each throws a 40 degree spot beam. Colour temperature is fixed per unit, so you choose 2700K, 3000K or 4000K at the point of order. Installing it is a case of pushing the spike into soft ground, aiming the heads, then joining the tail to your buried supply cable with a waterproof connector.

Where It Works Best

Path edges are the obvious home for it. One head lights the walking surface while the other picks out the planting, so a single line of SL230s does two jobs down the length of a garden path. It earns its keep on steps and level changes too, where the second head can be angled back to catch the riser. Set among shrubs it will graze a fence panel and uplight a small multi stem tree at the same time. Along a driveway it marks the edge without the runway effect you get from a row of bollards. Because the whole fitting is on a spike it is just as happy in a large planter or a raised bed as it is in a border, and being low voltage it is a sensible choice for a garden that gets used after dark by children and pets.

About Collingwood Lighting

Collingwood designs and manufactures its LED products in Sywell, Northamptonshire, and has specialised in LED technology since 2002. The brand states it was among the first to bring fire rated, fully sealed for life and mains dimmable LED products to the UK electrical wholesale market. Collingwood has also been awarded an EcoVadis Gold medal, placing it in the top 5% of companies assessed worldwide for sustainability. For a fitting that will stand outside through British winters for years on end, that mix of UK engineering and a long view on product life counts for a lot.

Good to Know

• Covered by a 7 year Collingwood warranty.
• IP65 rated. That means fully protected against dust and against low pressure water jets from any direction, so driving rain and a garden hose are not a concern.
• Class III construction. It runs on safety extra low voltage and must be fed from a suitable SELV driver, never wired straight to the mains.
• Dimmable, but only with a driver that supports dimming. The DRV350700TD is the dimmable option in Collingwood's own driver range.
• Wiring is series, so plan the run length and the driver capacity before you start digging.
• CRI above 80 with SDCM3 colour consistency, so planting keeps its true colour and neighbouring fittings match each other.
• Rated LED life of 70,000 hours to L70. The LED is integrated, so there is no lamp to replace.
• Maximum ambient temperature is 35 degrees C.
• Weight is 1.5 kg. The heads are 62.5mm in diameter and the spiked pole stands 845mm tall.
• Care is simple. Wipe the lens with a damp cloth now and then, and keep planting trimmed back so the beam is not blocked.
• Waterproof junction boxes and gel filled connectors, references JB2, JB4 and JB6, plus the GH220 and GS220 anti glare hoods, are available separately.
• Moonlight Design recommends installation by a registered NICEIC electrician.

Questions People Ask

Does the Collingwood SL230 low voltage spike light include a driver?
No. The low voltage SL230 twin pole spike light is supplied without a driver. It needs a separate constant current LED driver running at either 350mA or 700mA, sized for the number of fittings on the circuit. Collingwood names the DRV150700, the dimmable DRV350700TD and the PSIP70036W among its recommended drivers for this fitting.

How bright is the Collingwood SL230 twin pole spike light?
Each of the two heads on the Collingwood SL230 draws 4.4W when driven at 350mA, and Collingwood publishes 580 lumens per head at that setting. Driven at 700mA each head draws 9.2W and produces more light again. Both heads throw a 40 degree spot beam.

Can the two heads be aimed separately?
Yes. Each head on the Collingwood SL230 twin pole spike light tilts through 90 degrees and rotates through 330 degrees independently of the other, so one head can uplight a tree while the second lights the path underneath it.

Is the colour temperature switchable on this fitting?
No. Collingwood lists the low voltage SL230 as a single colour temperature product, so each unit is built at one fixed colour temperature chosen at the point of order from 2700K, 3000K or 4000K. It cannot be changed once the light is installed.

Is the SL230 suitable for a garden near the sea?
Yes. Collingwood lists the SL230 as suitable for coastal areas. The black version is built from anodised aluminium and sealed to IP65, which is what allows it to cope with salt laden air and wind driven rain.

Heads 62.5mm diameter / Spike 845mm height (refer to spec for details)
