LuxR Modux 2 Square Light Wash - 2 Facet - Copper - Low Voltage

A Copper Square Light Wash with Two Facets

The LuxR Modux 2 Square Light Wash is a very small low voltage feature light that casts a narrow decorative band of light 5º below the flange lip. This is the 2 facet version: a facet is the opening that the light is emitted from, so this one has two openings. For the exact light distribution, please check the product spec sheet or contact us. The recessed body is 41mm across and 62mm long, with a square flange.

Copper That Develops a Natural Patina

This version is made from copper. It starts warm and bright, then slowly develops a soft natural patina outdoors, so the flange mellows against brick, timber or stone. The light source is a 2 watt Cree LED.

Choose Your Colour Temperature

• Colour temperature: 2200K is a very warm glow that suits copper well, 2700K and 3000K are warm white, and 4000K is a crisper neutral white.

How It Works

The light is recessed into a wall, post or step riser using a 43.5mm cut out. The fitting runs on low voltage, so it needs a suitable constant current driver, which is not included, and it is wired in series. It is dimmable when paired with a suitable dimmable driver. A 1m cable is supplied. The LED can be replaced or swapped for a colour LED, and the optic can be changed to alter the beam width.

Moonlight Design recommends that all lighting should be installed by a registered NICEIC electrician.

Where It Works Best

Use it on a wall or post, beside a doorway or along a path. It also lights the wall next to step treads or the treads themselves. Moonlight Design uses LuxR fittings in its own garden lighting designs and installations. It is also available in M4.

Good to Know

• Dimensions: recessed body 41mm diameter and 62mm long, cut out 43.5mm, flange 53mm wide and 11mm deep. Supplied with 1m of H05RN-F cable.
• Rated IP68 for protection against dust and water, so it is built for outdoor use.
• 2 watt LED at 85 lumens per watt, low voltage, series wiring.
• Warranty: 10 years on the body, with 5 years on the LED.
• Designed, engineered and hand assembled in Auckland, New Zealand, by the makers of Hunza.
• Usually ships in 2 to 3 days. If out of stock, allow 3 to 5 weeks.

Questions People Ask

What is a facet?

A facet is the opening that the light is emitted from.

What is the difference between 1 facet and 2 facet?

A facet is the opening that the light is emitted from. The 1 facet version has one opening and the 2 facet version has two. The two versions share the same body and flange size. Please check the product spec sheet or contact us to confirm the exact light distribution for your project.

What size hole do I need?

The cut out is 43.5mm. The recessed body is 41mm across and 62mm long, and the flange is 53mm wide.

Does it come with a driver?

No. It is a low voltage fitting and needs a suitable constant current driver, sold separately. A dimmable driver lets you dim the light. We recommend a registered NICEIC electrician installs it.

Will the copper change colour?

Yes. Copper develops a natural patina outdoors over time, so the finish will soften and darken gradually. This is normal and is part of its appeal.

Can I change the LED later?

Yes. The LED can be replaced or swapped for a colour LED, and the optic can be changed to alter the beam width.

Recessed Body
Diameter: 41mm
Length: 62mm
Cut-Out: 43.5mm

Flange
Width: 53mm
Depth: 11mm

Cable: Supplied with H05RN-F 1m
(refer to spec for more information)

• M2 Squarelight
