Collingwood PSDIP6024 60W 24V LED Driver - IP66 - 1-10V Dimmable

A 60W driver that is happy sitting outside

Most LED drivers have to be tucked away in a dry cupboard or a separate weatherproof box. The Collingwood PSDIP6024 does not. It is a 60W 24V LED driver sealed to IP66, so it can be fixed in an exposed position and left to get on with it. That makes it the quiet problem solver on garden and terrace jobs, where the fittings are outside and the nearest dry void is a long cable run away.

It is a constant voltage unit, which is the type 24V LED strip and Collingwood's 24V ground lights are built to run from. Buyers usually come looking for a 60W 24V LED driver, an IP66 LED driver for outdoor use, or a 1-10V dimmable 24V driver, and this one answers all three.

The unit itself

The body is extruded aluminium with deep cooling fins along both sides, finished in plain silver grey. It measures 200mm long, 70mm wide and 45mm deep, and weighs 1.2kg, so it has real heft to it. Flat mounting flanges at each end let it be screwed straight to a wall, a joist or the back of a plinth. Mains flies in at one end and the 24V output leaves at the other, with the dimming pair alongside. There is nothing decorative about it, because it is meant to be hidden, but the finned casting is the reason it can be sealed shut and still shed its heat.

How It Works

The PSDIP6024 takes 220 to 240V AC mains and converts it to a steady 24V DC supply, up to 60W and 2.5A maximum. Because the output voltage is fixed, you load it up to that 60W ceiling with as many fittings as the wattage allows rather than matching a single fixture. Collingwood's own driver guide lists it as running up to 120 GL018 ground lights, or around 6.2 metres of its LSV45 LED strip. It draws up to 71W at the input side.

Dimming is 1-10V, and it needs a separate dimming interface wired into the control pair to actually dim. Collingwood lists the PDCINT 1-10V interface for its 24V drivers. Left on its own the driver simply runs at full output, which is fine if the circuit is only ever switched on and off. Built in protection covers short circuit, overload and overheating. Supplied as the driver alone, with flying leads for mains, output and dimming.

Where It Works Best

This is the driver for schemes where the power supply cannot be kept dry. Think a run of ground lights down a driveway, deck lighting on a raised terrace, or LED strip washing a garden wall, with the driver clamped to a fence post, a soffit or the underside of decking rather than routed back indoors. It is equally at home in plant rooms, garages and utility spaces where dust and splashes are a fact of life. The 60W ceiling suits a single zone or a modest run rather than a whole garden, so on larger schemes it tends to be used two or three at a time, one per circuit. Because it is sealed to IP66 it is also suitable for bathroom installations, and our guide to bathroom lighting zones explains how the zones work.

About Collingwood Lighting

Collingwood designs and manufactures its LED products in Sywell, Northamptonshire, and has worked with LED technology since 2002. The brand states it was among the first to bring fire rated, fully sealed for life and mains dimmable LED products to the UK electrical wholesale market. It has also been awarded an EcoVadis Gold medal, which places it in the top 5% of companies assessed worldwide for sustainability.

Good to Know

• Backed by a 3 year guarantee.
• Rated IP66, meaning fully protected against dust and against powerful water jets from any direction, so no separate weatherproof enclosure is needed.
• Class I, so the unit must be earthed.
• Constant voltage 24V DC output. It will not run constant current fittings, and the total load must stay within 60W.
• Dimming needs a separate 1-10V dimming interface on the control pair. On its own the driver is fixed output.
• Rated for ambient temperatures from minus 25C to 45C. Give the finned casing room to breathe and do not bury it in insulation.
• Body is aluminium, 200mm x 70mm x 45mm, weighing 1.2kg. Allow for that when choosing a mounting point.
• Care is simple. Brush dust and cobwebs off the fins occasionally so the heatsink keeps working.
• Moonlight Design recommends installation by a registered NICEIC electrician.

Questions People Ask

What can a Collingwood PSDIP6024 driver power?
The Collingwood PSDIP6024 is a constant voltage driver that powers any 24V DC LED load up to a combined 60W. Collingwood's driver guide lists it as suitable for up to 120 GL018 ground lights or roughly 6.2 metres of LSV45 LED strip.

Does the PSDIP6024 dim on its own?
No. The PSDIP6024 is a 1-10V dimmable driver, which means it responds to a 1-10V control signal fed to its dimming pair, but it does not generate that signal itself. A separate 1-10V dimming interface, such as Collingwood's PDCINT, has to be wired into the circuit before the output will dim.

Can the PSDIP6024 be mounted outdoors without a weatherproof box?
Yes. The Collingwood PSDIP6024 is sealed to IP66, which covers total dust ingress protection and protection against high pressure water jets, so it can be fixed in an exposed outdoor position without an additional enclosure.

What is the maximum output current of the PSDIP6024?
The PSDIP6024 delivers up to 2.5A at 24V DC, giving its 60W maximum output. On the mains side it draws up to 71W from a 220 to 240V AC supply.

How big is the Collingwood PSDIP6024 and what is it made of?
The PSDIP6024 has a finned aluminium housing measuring 200mm long by 70mm wide by 45mm deep and weighing 1.2kg. The aluminium body doubles as the heatsink, which is what allows the driver to be fully sealed.

200mm length x 70mm width x 45mm depth
