Orluna L-N-20 Non-Dimmable Driver - 24V DC 20W

Orluna L-N-20 Non-Dimmable Driver

The Orluna L-N-20 is a 24V DC constant voltage driver without dimming, designed to feed low voltage Orluna fittings on circuits where fixed, full output is all that's needed.

Matching This Driver To Your Fitting

Because this is a constant voltage driver, the key check is load: add up the wattage of the Orluna fitting or fittings you plan to run and make sure the total sits within the driver's 20W capacity at 24V DC. Confirm the fitting is designed to run at 24V DC before installing, since constant voltage drivers and constant current drivers are not interchangeable.

How It Works

The L-N-20 converts mains voltage into a fixed 24V DC output, supplying up to 20W to connected fittings at a constant, non dimmable level. With no dimming circuitry to account for, it is a simple, reliable way to power a fitting that is always run at full output.

Where It Works Best

At 20W, the L-N-20 suits smaller runs of 24V DC Orluna fittings where dimming is not required, for example a single low voltage fitting or a small cluster kept at constant output. Where dimming is needed on the same 24V DC platform, the L-M-30 and L-M-90 mains dimmable drivers cover 30W and 90W respectively. Site it somewhere accessible, since as a remote driver it will need to be reached if it ever requires servicing.

Made By Orluna

Orluna's story starts in 1973, when a group of aeronautical engineers began applying LED technology to civil and military uses where efficiency and mechanical reliability mattered more than anything else, long before LEDs were common in architectural lighting. That grounding in precision engineering still shapes how Orluna specifies the control gear behind its fittings today, drivers included.

Good To Know

• Output: 24V DC, fixed voltage
• Maximum power: 20W
• Input: Mains voltage
• Dimming: Not dimmable, constant output only
• Suitable for use with Orluna 24V DC fittings within the rated load
• Covered under Orluna's 20 year spares and repair programme as a replaceable component

Questions People Ask

Can the L-N-20 be dimmed? No, it is a non dimmable driver that runs connected fittings at a constant, fixed output.

How do I know if my fitting's load is within range? Add up the wattage of every Orluna fitting on the circuit and make sure the total stays at or below the driver's 20W rating at 24V DC.

Is there a dimmable version of the L-N-20? Yes, the L-M-30 and L-M-90 offer the same 24V DC platform with mains dimming, at 30W and 90W respectively.

35mm height x 109mm length x 50mm width
