Orluna L-D-80 Dali Dimmable Driver - 24V DC 80W

Orluna L-D-80 Driver

The Orluna L-D-80 is a Dali dimmable driver from Orluna's own L series, with a fixed 24V DC output rated at 80W, the highest power unit in this batch.

Matching This Driver To Your Fitting

As a Dali driver, the L-D-80 dims digitally, so it can be individually addressed, grouped and scene set from a Dali system. Fixed voltage drivers are matched to specific loads, so confirm the L-D-80 against your Orluna fitting's driver compatibility before installing.

How It Works

The L-D-80 delivers a fixed 24V DC at up to 80W, operating as a constant voltage driver suited to 24V DC LED loads rather than a current fed engine. Dimming is handled entirely through the Dali digital protocol, allowing precise, repeatable control across a scheme rather than a single shared analogue line.

Where It Works Best

At 80W, the L-D-80 is the highest power driver in Orluna's L series here, suited to larger 24V DC installations or multiple light points drawing more load than the 50W L-D-50 can support, while retaining Dali's addressing and scene setting capability. Where analogue 1 to 10V control is preferred instead, the equivalent L-0 units offer a fixed voltage alternative.

Made By Orluna

Orluna's early work in the 1970s applied LED technology to civil and military applications where efficiency, longevity and mechanical reliability mattered most, long before LEDs found their way into architectural lighting. That same emphasis on reliability sits behind higher power drivers such as the L-D-80 today, chosen to support a fitting for the long term rather than just at the point of sale.

Good To Know

• Output voltage: 24V DC fixed
• Power: up to 80W
• Dimming protocol: Dali digital addressable
• Driver line: Orluna L series
• Compatibility: confirm against your specific Orluna luminaire before ordering

Questions People Ask

Q: What is the maximum load the L-D-80 supports?
A: It is a constant voltage driver with a fixed 24V DC output up to 80W.

Q: Can the L-D-80 be used in a Dali scene setting scheme?
A: Yes, as a Dali driver it supports individual addressing, grouping and scene set control.

Q: How does the L-D-80 compare to the L-D-50?
A: Both are 24V DC Dali drivers from the same L series, but the L-D-80 is rated at 80W against the L-D-50's 50W.

22mm height x 346mm length x 32mm width
