A Simple Fix for Mounting Your Emergency High Bay
This bracket exists for one job. It lets the emergency version of Collingwood's high bay luminaires mount to lighting trunking, or straight onto a surface if trunking isn't an option. No adapters, no guesswork, just a bracket built to match the screw layout on the emergency model.
Built for the Emergency Version Only
It's finished in matte black steel, a plain shape with two feet and a bridge across the top. Three oval holes in the top bar give you a central M20 thread for trunking, plus the spacing needed to bolt it directly to a wall, ceiling or frame. It is made specifically for the emergency high bay range, not the standard version, so the screw positions won't line up with a non-emergency luminaire.
How It Works
- Remove the four screws on top of the emergency luminaire
- Slot the bracket over the luminaire so the holes line up
- Replace the same four screws to lock the bracket in place
- Mount via the central M20 thread onto trunking, or bolt the bracket's feet directly to a surface
Where It Works Best
This is a fitting job for warehouses, distribution centres, workshops and any large indoor space where emergency high bay luminaires are already installed or specified. It suits sites running lighting trunking as the main containment system, and it's just as useful where an electrician needs to fix the luminaire straight to a ceiling or support frame instead.
About Collingwood Lighting
Collingwood Lighting designs and manufactures its LED products from Sywell in Northamptonshire, and the brand has focused on LED technology since 2002. Collingwood states it was among the first to bring fire rated, fully sealed for life and mains dimmable LED products to the UK electrical wholesale market. The company has also been awarded a Gold medal by EcoVadis, placing it among the top 5% of companies assessed globally for sustainability.
Good to Know
- Carries a 5 year warranty
- Designed only for the emergency version of Collingwood's high bay luminaires. Check your luminaire is the emergency model before ordering
- Mounts via a central M20 thread to trunking, or bolts directly to a surface
- Fits using the luminaire's own existing top screws, no extra fixings needed for the bracket to luminaire connection
- Moonlight Design recommends installation by a registered NICEIC electrician for the high bay luminaire itself
Questions People Ask
Will this bracket fit a standard, non-emergency high bay luminaire?
No. The screw layout is specific to the emergency version of Collingwood's high bay range, so it won't line up with the standard model.
Do I need lighting trunking to use this bracket?
No. The bracket can be bolted directly to a wall, ceiling or frame if trunking isn't available, as well as fixed to trunking via its central M20 thread.
What's included with the bracket?
Just the bracket itself. It reuses the four screws already fitted to the top of the emergency luminaire, so no extra fixings are needed to attach it.
What warranty does it carry?
The bracket carries a 5 year warranty.
