Orluna D-300-1 EldoLED Dali Dimmable Driver - 300mA 20W

Orluna D-300-1 EldoLED Driver

The Orluna D-300-1 is an EldoLED built Dali dimmable driver rated at 300 milliamps and 20W, the highest current option in Orluna's Dali EldoLED range.

Matching This Driver To Your Fitting

As a Dali unit, the D-300-1 dims digitally, allowing individual addressing, grouping and scene control from a Dali system rather than a single analogue dimming line. Higher current drivers are matched to specific Orluna luminaires, so check the D-300-1 against your fitting's driver specification before installing.

How It Works

The D-300-1 supplies a constant 300 milliamps, the highest current rating in Orluna's Dali EldoLED range, though its power output tops out at 20W rather than the 30W of its 0 to 10V equivalent, the 0-300-2. As an EldoLED unit, it shares EldoLED's industry standing for precise, flicker free dimming performance, controlled here entirely through the Dali digital protocol.

Where It Works Best

At 300mA, the D-300-1 is suited to Orluna fittings with a higher current LED engine that also require Dali's digital addressing and scene setting capability, distinguishing it from the lower current D-100 and D-120 as well as from its 0 to 10V analogue counterpart, the 0-300-2, which carries a higher 30W rating at the same current.

Made By Orluna

Orluna remains a British designed and manufactured brand, with precision engineering and long term product support built into every part of a fitting, control gear included. A high current unit like the D-300-1 is specified with that same long term view, chosen for reliability over the course of a project rather than the lowest cost on a spec sheet.

Good To Know

• Output: 300mA constant current
• Power: up to 20W
• Dimming protocol: Dali digital addressable
• Driver: EldoLED engineered
• Compatibility: confirm against your specific Orluna luminaire before ordering

Questions People Ask

Q: What is the power rating of the D-300-1?
A: It is rated at 300mA with a maximum output of 20W.

Q: How does the D-300-1 compare to the 0-300-2?
A: Both supply 300mA, but the D-300-1 dims via Dali and is rated at 20W, while the 0-300-2 dims via 0 to 10V analogue and is rated at 30W.

Q: Is the D-300-1 suitable for scene setting installations?
A: Yes, as a Dali driver it supports individual addressing and scene control, subject to confirming compatibility with your Orluna luminaire.

160mm length x 42mm width x 31mm depth
