Orluna 0-100 EldoLED 0-10V Dimmable Driver - 100mA 20W

Orluna 0-100 EldoLED Driver

The Orluna 0-100 is an EldoLED engineered 0 to 10V dimmable driver, built to deliver clean, stable current to compatible Orluna luminaires. Rated at 100 milliamps and 20W, it is the entry point in Orluna's 0 to 10V EldoLED range.

Matching This Driver To Your Fitting

This driver uses 0 to 10V analogue dimming, one of the most widely specified protocols in architectural lighting, controlled via a standard 0 to 10V dimmer or lighting control system. Because Orluna luminaires are built around specific driver and LED engine pairings, always confirm the 0-100 is the correct spec for your chosen fitting before installing, checking current draw and dimming protocol against the luminaire's own specification.

How It Works

Supplying a constant 100 milliamps at up to 20W, the 0-100 is specified in line with standard constant current LED driver practice, an approach suited to fixed output LED engines run in series. As an EldoLED unit, it carries EldoLED's industry reputation for precision dimming and flicker free performance at the low end of the dimming curve, control that becomes noticeable the moment a fitting is dimmed down rather than simply switched on.

Where It Works Best

The 100mA rating makes the 0-100 the lightest duty option in Orluna's 0 to 10V EldoLED trio, suited to smaller architectural fittings and single LED engine applications where a full 300mA is unnecessary. It sits alongside the 120mA 0-120 and the 300mA 0-300-2 as current increases for higher output engines, so selecting the right current match matters as much as the dimming protocol itself.

Made By Orluna

Orluna's story began in 1973, when a group of aeronautical engineers began applying LED technology, then still rare outside civil and military use, to problems of efficiency, longevity and mechanical reliability. That same engineering discipline sits behind control gear like the 0-100 today, chosen because a premium fixture is only as dependable as the driver running it.

Good To Know

• Output: 100mA constant current
• Power: up to 20W
• Dimming protocol: 0 to 10V analogue
• Driver: EldoLED engineered
• Compatibility: for use with compatible Orluna fittings, confirm against your luminaire's spec before ordering

Questions People Ask

Q: What dimming protocol does the Orluna 0-100 use?
A: The 0-100 uses 0 to 10V analogue dimming, controlled via a standard 0 to 10V dimmer or lighting control system.

Q: Is the 0-100 compatible with any Orluna fitting?
A: It is designed for use with compatible Orluna fittings, but current and protocol should always be checked against the specific luminaire before installing.

Q: What is the output rating of the 0-100?
A: It supplies 100mA at up to 20W.

160mm length x 42mm width x 31mm depth
